Anti-terrorism Hydraulic Security Road Blocker , Full Automatic A3 Steel Road Blocker System
Keywords:
Hydraulic blocker, hydraulic road blocker, automatic rising blocker, automatic blocker, LED bollards, retractable road blocker, automatic traffic road blocker, anti-terrorism remote control blocker, fixed road blocker, 304 stainless steel road blocker, access control system blocker, security road blocker, safety road blocker, ground road blocker, metal road blocker, hydraulic rising blocker.
Introduction of hydraulic road blocker:
The Hydraulic Road Blocker is the vehicle control device which can be either integrated with various parking systems or installed as single unit, designed as an effective means of controlling access to high security areas such as: airports, ports, customs, governmental buildings, banks, penitentiaries, power stations, military sites, stores, embassies, warehouses, etc. The hydraulic road blocker is designed to guarantee the full level of security.
Features of hydraulic road blocker:
- Strong and durable structure, high load bearing, movement smooth, low noise, fast speed, long service life.
- Adopting PLC control, system operation is stable and performance is reliable., easy to integrate
- Supporting the gang control with parking barrier or other equipment. It can also work with other access control system.
- Adopting the advanced hydraulic drive technology. The whole system is high security, reliability, and stability.
- Manual hydraulic system meet the requirement of fire management (In case of power failure or malfunction)
- Remote control device: Through wireless remote control, it can control the rising and falling of road blocker within distance of 30 meters
- Convenient to maintain: in the case of structural failure or machine maintenance, you can loose the screw on the cover and take off the 16mm cover plate for corresponding operation.
Specifications of hydraulic road blocker:
| Item Number |
GAT-GAT-LZ708 |
| Size |
L 2500* W 920* H 760 mm(size could be adjusted ) |
| Rise height |
450 mm |
|
Power
|
AC220C/380V
|
|
Operating Temperature
|
-10°C~65°C
Waterproof, Dustproof
|
|
System Power
|
1.5KW/2.2KW/3.7KW/5.5kw(heavy-duty)
|
|
Up&down time
|
3~6 seconds(can be adjustable)
|
|
Parts of Blockers
|
1,Blocker Body
2,Automatical Control Board
3,Hydraulic Pressure Integration
|
|
Dia.of blockers
|
168mm ±2mm
220mm ±2mm
275mm ±2mm
|
|
Communication Distance
|
≤1200M
|
|
Thickness size
|
10mm ±1mm Optional
|
|
Communication Connection
|
RS485 interface
|
|
Material
|
A3 steel, spray anti-rust paint;
|
|
Colour
|
Various color optional
|
| Rising Time |
2 ~ 4S (adjustable) |
| Falling Time |
2 ~ 4S (adjustable) |
|
Applications
|
Highway Charging,Airport, Gov.
Military Area, Banks, Ports&Embassy
|
Feature and function:
1. Durable,Overload,Operate Smoothly,Low Noise,Fast speed up&down
2. Micro control technology makes bollards work stable and reliable,Easy integrate to other
systems
3. Compatible with road barrier,Turnstiles and other access system control to achieve automatic control
4. Advanced mature Hydraulic pressure technologies
5. Remote control system realize wireless control up&down within 30 meters range
6. Customized for different users requests
7. Controller display : LCD and LED
8. Swiping card system: built-in card reader to control bollards up&down
9. Road barrier integrate with Bollards : built-in access control realize road barrier,A/C and bollards in one-card
10. Connected with Computer Management OR Charging Systems
Competitive Advantage:
1. More than 10 years powerful ODM/OEM ability,could make product shape design,custom logo,custom package.
2. We can provide not only product, but also system software management.Save your time and cost.
3. Special service from Goldantell:
For repairing,no need you return back product,only need you take a video,our engineer will instruct you,if spare parts was damaged in 1 year,we will send you spare parts by fastest express,you no need bear any fee.
4. Friendly and professional customer service people help you in 16 hours.
Application:
Road blocker are widely used in Subway Station, Hoverport,Tourism,Sports,Exhibition, Swimming Hall,
Hotel,Residence,Area,Enterprise’s Entrance and Exit Attendance,Gateway Guard,Charge,Management,
Special Access Control.
