Product Details:
Payment & Shipping Terms:
|
| Product Name: | 304 SUS Speed Turnstile Gate | Size Of Product: | 1400*310*1000mm |
|---|---|---|---|
| Package Size: | 1510*380*1080mm | Material: | 304 Stainless Steel/316 Stainless Steel |
| Type: | Speed Gate | Compatible: | RFID Reader&Fingerprint Reader ,Coin Access,QR Code Reader,Bar Code System,ESD Tester Access Control, Remote Button |
| Net Weight: | 70KG | Gross Weight: | 80KG |
| Application: | Office, Building, Hotel, Club, Etc. | ||
| Highlight: | turnstile security gate,waist high turnstiles |
||
Security Fashionable Design Speed Gate With Glass Materail High Working Seed For Public Service
Description:
1. Goldantell smart translational speed gate turnstile is s a high- tech product which mainly provides intelligent management to passageway. It is a upgrade product of intelligent tripod turnstile and swing barrier. this product is finely processed with complete functions and high level, suitable for high- level
neighborhoods, intelligent buildings, hotel, subway, port and club,etc.
2. This equipment is subtly integrated with machine, electronics, micro- processor control and ID identification, provides convenience for the use of card reader identification equipment, such as IC card,
ID card, bar code and fingerprint. It can carry out intelligent control and management to the passageway through choosing various identification equipment and adopting fair, reliable security protection, alarming equipment and direction indicating equipment...
3. Classified into two kinds: single motor (suitable for single passageway and multiple passageway.); Double motors (suitable for multiple passageways)
Specifications:
| Technical Parameters | |
| Housing material: | domestic standard 304# stainless steel |
| Size: | 1400mm (L) * 310mm (W) * 1000mm (H) |
| Working voltage: | AC220±10%V 50±10%HZ |
| Drive motor: | DC24V brush motor |
| Retractable arm length: | 235 mm |
| Time to work after power on: | 3 seconds |
| Passage width: | 550 mm |
| Time of opening: | 1second |
| Pass speed: | 40 persons/min (open), 25-30 persons/min (closed) |
| Emergence: | When power off, arm open automatically |
| Normal running life: | 3 million |
| LED light: | direction arrow |
| Direction: | single or bi-directional (optional) |
| Working environment: | indoor/outdoor (with a tent over) -10℃～70℃ |
| Relative humidity: | ≤90% coagulation free |
| Communication interface: | standard RS485 interface, distance ≤1200m |
| Input interface: |
+12V level signal or pulse width>100ms 12V pulse, drive current>10mA |
Functions & features:
1. With function of self-examine and alarm, it is convenient for maintenance and use.
2. Being able to program running status by the small keyboard in the main board
3. Preventing pedestrians from being nipped and from hurt
4. Light and sound alarm function including the illegal in and the tail
5. Doors are automatically locked until opening signal is received.
6. Doors synchronization (adjustable)
7. Automatically reset function: It will automatically lock if the pedestrian hasn’t passed through the channel in the pre-set time after the opening. The passing time is adjustable
8. Information display option (LCD display screen)
9. Audible sound prompt
System Integration
Integrate with access control system required by customers, and built-in reader appointed by customer.
Integrate with visitor management system.
Integrate with ticketing system.
With half High Sliding Arms below (optional)
Hot-selling Recommended below:
More options
Competitive Advantage:
1. More than 10 years powerful ODM/OEM ability,could make product shape design,custom logo,custom package.
2. We can provide not only product, but also system software management.Save your time and cost.
3. Special service from Goldantell: For repairing,no need you return back product,only need you take a video,our engineer will instruct you, if spare parts was damaged in 1 year,we will send you spare parts by fastest express,you no need bear any fee.
4. Friendly and professional customer service people help you in 16 hours.
