Anti-Rust Waterproof SUS304 Turnstile Outdoor Speed Gate with LED Visual Guidance for Park and Gated Community CE

  • Anti-Rust Waterproof SUS304 Turnstile Outdoor Speed Gate with LED Visual Guidance for Park and Gated Community CE
  • Anti-Rust Waterproof SUS304 Turnstile Outdoor Speed Gate with LED Visual Guidance for Park and Gated Community CE
Place of Origin Guangdong,China
Brand Name Goldantell
Certification CE certificated
Model Number GAT-330 new
Minimum Order Quantity 1pc
Price Negotiable
Packaging Details carton +crate, or closed wooden case
Delivery Time 5-7 working days after received your payment
Payment Terms T/T,Western Union,Paypal
Supply Ability 1,000pcs per month
Product Details
Working Environment -10-70 Degree Size 1200L*W280*H1000mm
Material 304 Stainless Steel,thickness Is No Less Than 1.3mm Arm Length 510mm
Power Supply 110~240 V(AC) Pass Speed 30 Persons/min
Power Consumption 20W Communication Interface RS485, TCP/IP
Highlight

SUS304 waterproof turnstile gate

,

outdoor speed gate with LED

,

tripod turnstile gate for park
Leave a Message
Product Description
Product Overview

The Anti-Rust Waterproof SUS304 Turnstile Outdoor Speed Gate is a simple, economical, and compact entrance and exit solution designed for parks, gated communities, and a wide range of other venues. It integrates seamlessly with any access controller system, including RFID devices, push buttons, fingerprint readers, and biometric devices.

Available in single-motor (single passage) and double-motor (two simultaneous passages) configurations, this turnstile is portable and suitable for factories, stadiums, power plants, amusement parks, ski resorts, and more. In the event of an emergency or power failure, the horizontal arm drops down automatically to allow free passage.

Specifications
Item Number GAT-330
Item Type Full automatic, semi-auto, or manual operation
Housing Material Standard 304# stainless steel
Size 1200 * 280 * 1000 mm
Working Voltage AC220/110 ±10%V; 50 ±10%HZ
Power Consumption 20W
Passage Width ≤600 mm
Pass Speed 30 persons/min
Normal Running Life 3 million cycles
LED Light Optional, direction arrow
Direction Single or bi-directional (optional)
Emergency Mode When powering off, arm opens
Mechanism Solenoid lock
Working Environment Indoor / outdoor available
Communication Interface RS485, TCP/IP
Features & Functions
  • Auto replacement function — re-positions after each person passes.
  • Anti-tail function — auto-locks once the arm turns 120° or 60°.
  • Arms auto-drop when power off, ensuring unblocked passage during accidents.
  • Railing disengages when power is off.
  • Counting function — if a card is read N times, N persons can pass before the railing closes (N ≤ 8, optional).
  • Voice prompt and display screen available (optional).
  • External counter can be connected to count the number of passed people (optional).
  • RS485 communication — PC command through serial port is supported (optional).
  • Alarming output for pushing the railing without permission (optional).
  • Single-direction or double-direction operation (optional).
Packing & Shipping
Package Details
  • Inner package — bubble bags
  • Outer package — whole crate package is advised, or wooden case package
Shipment Terms
  • If <10 pcs, ship within 7 working days
  • If >50 pcs, ship within 10–15 working days
  • For customized products, ship within 7–12 working days according to detailed customization requirements
Product Photo
Anti-rust waterproof SUS304 stainless steel tripod turnstile speed gate with LED visual guidance, shown in an outdoor park or gated community setting
Frequently Asked Questions
Q: Can you produce according to the samples?

A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

Q: What is your sample policy?

A: We offer samples if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.

Q: Do you test all your goods before delivery?

A: Yes, we have 100% testing before delivery and will provide a testing video for your confirmation before shipment.

Application Projects
  • Gym
  • Office Buildings
  • Hotel
  • Factory
  • Bank
  • Prison
  • Hospital
  • School
