Bi Directional Revolving Door Turnstile With NFC Passage Entrance Control System
| Place of Origin | Guangdong,China |
|---|---|
| Brand Name | Goldantell |
| Certification | CE certificate |
| Model Number | GAT-306 series |
| Minimum Order Quantity | 1pc |
| Price | negotiation |
| Packaging Details | closed wooden case |
| Delivery Time | 7 working days after received your payment |
| Payment Terms | T/T,western Union,LC,Paypal |
| Supply Ability | 1,000pcs per month |
Contact me for free samples and coupons.
WhatsAPP:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Communication | RS485 Communication | Application | Outdoor,hotel,airport |
|---|---|---|---|
| Odm/oem | Accepted | Material | 304 Stainless Steel |
| Direction | In Or Out, Or Two Ways | Power Supply | 110~240 V(AC) |
| Warranty | 1 Year | Passage Width | 600mm |
| Highlight | NFC Passage Tripod Turnstile Gate,600mm Tripod Turnstile Gate,Entrance Control Tripod Turnstile Gate |
||
Product Description
Bi Directional Revolving Door Turnstile With NFC Passage Entrance Control System
Bi-directional Revolving Door Turnstile With NFC Passage Entrance Control System Semi-automatic Single Core
Quick Description Of Revolving Door Turnstile
- The portable turnstile is ideal for various applications including athletic facilities, cafeterias, schools, amusement parks, stadiums, and office buildings.
- Operates bi-directionally with configurable modes: one direction permitted/forbidden or one direction charged/free, adjustable via control board buttons.
- Three rods automatically lift when power is cut off for emergency passage.
- CE certified construction with brushed stainless steel body for durability and rust resistance.
- Available in semi-automatic, manual, and full automatic operation modes (arms automatically engage when powered).
Technology Parameters Of Revolving Door Turnstile
| Size | 420mm (L) * 330mm (W) * 1000mm (H) |
|---|---|
| Working voltage | AC110/220±10%V, 50±10%HZ |
| Working movement | DC24V solenoid valve |
| Arm width | 510 mm |
| Support force of arm | 40kg |
| Passage width | ≤600 mm |
| Time of opening | 0.2 second |
| Pass speed | 30 persons/min |
| Emergency feature | Arms open automatically when power fails |
| Normal running life | 3 million cycles |
| LED light | Direction arrow indicator |
| Direction | Single or bi-directional (optional) |
| Working environment | Indoor/outdoor (with cover) -10℃~70℃ |
| Relative humidity | ≤90% (non-condensing) |
| Communication interface | Standard RS485 interface, distance ≤1200m |
| Housing material | 304# stainless steel |
| Input interface | +12V level signal or pulse width>100ms 12V pulse, drive current>10mA |
Features & Functions Of Revolving Door Turnstile
- Standard electronic interface with internet remote control capability, compatible with various card readers.
- Open signal with optional memory function configuration.
- Anti-passback mechanism prevents reverse rotation after 60-degree arm movement.
- Hydraulic shock absorption for quiet operation and vibration reduction.
- Multiple control modes with easy management options.
- Automatic repositioning after passage.
Application Locations
Exhibition halls
Stadiums
Museums
Apartments
Residential areas
Movie theaters
Fitness gyms
Factories
Hospitals
Design Of Revolving Door Turnstile
Frequently Asked Questions
How about your package?
Seaworthy wooden case with foam protection.
Can your machines be used outside?
With waterproof function, suitable for outdoor use.
How about the lead time?
Regular products: 5-8 working days. Customized products: 9-13 working days.
What is your MOQ?
Any quantity is acceptable.
How about the payment method?
Standard products: 50% deposit, 50% balance before shipment.
