Product Details:
Payment & Shipping Terms:
|
Size: | L1200*W280*H1000mm | Passing Speed: | 40 Person/min |
---|---|---|---|
Material: | 304 Stainless Steel | Type: | Single Core Or Dual Core Unit |
Working Environment: | Indoor / Outdoor ( Shelter),-10-70℃ | Certification: | CE |
Warranty: | One Year | Power Supply: | AC100V-240V |
Highlight: | NFC Wristbands Silicone Turnstile Security Doors,40 Person/min Turnstile Security Doors,13.56MHz Security Turnstile Gate |
NFC wristbands silicone turnstile door Custom Access Control Card 13.56MHz Smart RFID gym access control door
Product Brief
1) Flap barrier gate can be compatible with face thermal detection, NFC/RFID card, QR code/ ticket scanner, ESD tester, fingerprint reader access control device used for staff, provide civilized , orderly access methods.
2) LCD screen: optional, supply more options for system requirement.
3) Higher flow rate and better anti-tailgate functions.
4) Single core (movement) structure or dual core (double movement) structure is equipped for different installation requirements.
5) Single wing or double wings structure is equipped for different requirements regarding Lane width.
6) Double protections of Mechanical and infrared anti-pinch function, providing more reliable and safer passing.
Technical specification
Size: | 1200mm (L) * 280mm (W) * 1000mm (H) |
Retractable arm length: | 285 mm ( can be custom-made) |
Pass speed: | 40 persons/min (open), 30-35 persons/min (closed) |
Passage width: | ≤600mm ( or <900mm width, custom-made) |
Normal running life: | 3 million |
Time of opening/closing: | 0.6 second |
Time to work after power on: | 3 seconds |
Reset time after break down: | 10 seconds |
Direction: | single or bi-directional (optional) |
Drive motor: | brushless motor ( or servo motor) |
Working environment: | indoor/outdoor (with a tent over) -10℃~70℃ |
Communication interface: | standard RS 485 interface, distance ≤1200m |
Input interface: | +12V level signal or pulse width>100 ms 12V pulse, drive current>10 mA |
Relative humidity: | ≤90% coagulation free |
Housing material: | domestic standard 304 # stainless steel |
Working voltage: | AC220±10%V 50±10%HZ |
Security Features
1. Auto close timer protection. Flap will auto close if there is no pedestrian pass through after the delay time elapsed. This prevent unauthorized user from sneaking into the building.
2. LED indicator function. LED indicator light is available at both directions to indicate if the lane is available to use (green arrow) or lane is closed for maintenance (red cross).
3. Emergency evacuation.During power failure, flaps will automatically open. Flap wing will automatically close back after power supply resumed.
4. It is with RS485 connection for far control arm up and down to satisfy the special needs or fire control requirements.
5. It is with a standard electrical interface to connect various kinds of readers and writers for easy integration and also computer far control and management can be realized by a computer.
Product Show
Project Application
FAQ
1. What is your MOQ?
Vivian: Any quantity is acceptable.
2. Can your machines be used outside?
Vivian: With waterproof function, could be used outside
3. What is the warranty for the machine?
Vivian: Within 1 year, if any quality problems, we will offer the accessories
4. Can I customize it?
Vivian: Yes, Welcome. We are the manufacturer, we have rich OEM/ODM experience for government, etc.
5. What are your terms of payment?
Vivian: 100% paid before shipment. We'll show you the photos or videos of the products and packages before you pay the balance.
6. What are your terms of delivery?
Vivian: EXW, FOB, CFR, CIF, DDU.
Package Info
1. Inside with a carton package.Then outside,there are 2 kinds of packages under your choice:
2. crate package and closed wooden package optional.
3. if <10pc, ship in 7 working days ; > 50, ship in 10-15 working days; For customized product, need 2-3 longer working days.
