Product Details:
Payment & Shipping Terms:
|
| Product Size: | 1200*280*1000mm | Communication Port: | RS485 ,TCP/IP |
|---|---|---|---|
| Application: | Movie Or Fitness Certer Or Hotel Or Restaurant Entrance | Product Name: | Width 900mm Double Wing Turnstile |
| Passway Width: | In 900mm (can Be Custom According To Your Requirement) | N.W: | 65kg |
| G.W: | 70kg | Material: | 304stainless Steel |
| High Light: | Acrylic Barrier Lane Speed Gate Turnstiles,Led Lighting Speed Gate Turnstiles,Solid Cabinet Speed Gate Turnstiles |
||
Product Introduction
1. Installation& application place: Subway, Airports, Stations,Library,Movie theaters, Fitness halls,Clubs, Swimming Hall,Fitness Gym.
2. Control system: can support RFID card ,Fingerprint system, Facial recognition system,or other different control system.
3. Special part: by using the Double Wings, the passway width can be 900mm.
Technical parameters
|
Working voltage: |
AC220±10%V, 50±10%HZ |
|
Pass width |
600mm, or 900mm (custom-made) |
|
Pass speed: |
40 persons/min (open), 25-30 persons/min (closed) |
|
Normal running life: |
3 million |
|
Time of opening/closing: |
0.6 second |
|
Time to work after power on: |
3 seconds |
|
Reset time after break down: |
10 seconds |
|
Working environment: |
indoor/outdoor (with a tent over) -10℃～70℃ |
|
Communication interface: |
standard RS 485 interface,distance ≤1200m |
|
Input interface: |
+12V level signal or pulse width>100 ms |
|
Relative humidity: |
≤90% coagulation free |
Design Show
Technology parameter of Face Recognition Device
1. standard face database 10,000 people, optional ID card reader, IC card reader and access control Wiegand signal output;
2. built-in MIC, audio output interface;
3. using 10.1 inches high-resolution top LVDS LCD screen;
4. using high-accuracy face recognition algorithm, can work offline, the fastest 0.2S to respond.
Function Description
The arm have the collision avoidance function: when the turnstile arm closed, if it is under the collision, the arm will open to protect the Transmission of inner machine.
Automatic Reset Functions: after you swap the card, during the specific time (the system is 10s), if you didn’t pass the turnstile, the system will cancel your authority automatically to pass the gate, (reset time is 1~60s you can adjust it what time is suit for you). totally meet the fire protection needs.
Infrared reset function (Optional:4 pairs or 6 pairs Infrared).
Infrared induction clamp function (4 pairs Infrared).
The turnstile can work with door access control system/ consumption system /biometric recognition system/ ESD system and so on.
The turnstile is bidirectional (pedestrian can enter and exit from one pair of turnstiles).
Turnstile can setting the working condition by press the button of main control board.
Anti- pinch function: turnstile have Mechanical/ infrared induction Anti- pinch functions( when it is meet the hinder during the reset time, the electrical machine closed work automatically in specified time, the turnstile will default the delayed and reset again till reset succeed).
The turnstile will closed the door when somebody enter the gate illegal, Tailgating or break into negative direction gate.
Before received the open signal, the turnstile will lock automatically.
Competitive Advantage
We can Offer the ODM/OEM service,could make product shape design,custom logo,custom package, custom size.
We can offer Turnstile and different kind of access control system to best support your project, and meet your demand.
Friendly and professional customer service people help you in 16 hours.
Excellent service from Goldantell:
For repairing,no need you return back product,only need you take a video,our engineer will instruct you,if spare parts was damaged in 1 year,we will send you spare parts by fastest express,you no need bear any fee.
