Shenzhen Goldantell Technology Co.,Limited
Quality is our culture!
|
Product Details:
Payment & Shipping Terms:
|
| Size: | 1400*310*1000mm | MAIN MATERIAL: | 304 Stainless Steel |
|---|---|---|---|
| Passing Speed: | 40 People/min | Power Supply: | AC 110~240 Volts |
| Application: | Entry / Exit Of Carport, Hotel, House | Delivery: | By Ocean / Air |
| Warranty: | 1 Year | Working Environment: | Indoor/outdoor,indoor / Outdoor |
| Unlock Time: | 0.2s | ||
| High Light: | Handicap Access Turnstile Gate,Anti Tailgating Access Turnstile Gate,Biometric Recognition Turnstile Entrance Gates |
||
Anti-Tailgating handicap access turnstile gate biometric recognition acceptor cards exit door
——————————————————————————
Brief Description
Goldantell Siding Turnstile Barrier Series can be integrated with any third-party device like card reader, bar code scanner, LCD panel,fingerprint and face identification device, even ESD tester device. With slim design and enhanced premium hair line polish, can elevate the prestige elegant impression while still effectively restricting unauthorized visitors from your entrance.
Technical specification
| Cabinet dimension | 1400 (L) x 310 (W) x 1000 (H) mm |
| Cabinet material | 304 stainless steel (316 ss can be custom-made) |
| Switching power supply | AC220±10%V 50Hz or AC110±10%V 60Hz |
| Flap opening/closing time | 0.6s |
| Stretching-out flap length | 285 mm |
| Access mode | single in/out or Bidirectional |
| Optimal flow rate | 40 persons/min (open), 25-30 persons/min (closed) |
| Reset time after break down | default 10s,can be changed to fit different demands |
—SAFETY IS PRIORITY
1. Safety function(anti-pinching). By default sliding wing will auto- reverse if IR sensor detected obstacle within the sliding wing area. This avoid sliding wing to accidentally hit onto to user. Can adding green/red/blue light lining effect along the edge of the sliding wing to ensure sliding wing is easily visible.
2. Anti-tailgating/ anti-retrogradation function: sliding wing can be set to pause if IR sensor detected obstacle nearby wing area during closing. sliding will resume closing once the obstacle is removed. This is to make it very difficult for following user to tail gate the first user.
DISPLAY for Half high sliding glass arm type
DISPLAY for Full high sliding glass arm type
1. Sliding turnstile barrier Series are widely suitable for indoor & outdoor applications.
2. It is an optimized affordable solution for Airport, Lobby, commercial office building, factory, bus station, game park, colleges, and banks. But the Optical Turnstile with colorful led light is NOT advised to be installed outdoor or near sea side.
