Product Details:
Payment & Shipping Terms:
|
Product Name: | Flap Barrier Gate | Size: | 1200/1400mm (L) * 300mm (W) * 1000mm (H) |
---|---|---|---|
Package Size: | 1280/1480*370*1070mm | Material: | 304 Stainless Steel |
Pass Speed: | 30-40 Persons/min | Interface: | RS485, TCP/IP |
Working Temperature: | -20~+80°C | Arm Length: | 285mm |
Thick Of Steel: | 1.5mm Or Custom Design | Power Supply: | 220~240 V(AC) |
Highlight: | Flap Barrier Turnstile,automatic flap barrier |
Access Control System auto turnstile full height , Safety outdoor Turnstile Gate
Technical parameters
Material |
domestic standard 304# stainless steel |
Working voltage | AC220±10%V 50±10%HZ |
Drive motor | DC24V brush motor |
Size | 1200/1400mm (L) * 280mm (W) * 990mm (H) |
Retractable arm length | 260 mm |
Passage width |
≤600mm |
Reset time after break down |
10 seconds |
Direction | single or bi-directional (optional) |
Working environment | indoor/outdoor (with a tent over) -10℃~70℃ |
Time of opening/closing | 0.6 second |
Pass speed | 40 persons/min (open), 25-30 persons/min (closed) |
Communication interface | standard RS485 interface, distance ≤1200m |
Input interface | +12V level signal or pulse width>100ms 12V pulse, drive current>10mA |
Classified into two kinds:
1 . Single motor : suitable for single passageway and multiple passageway
2 . Double motors : suitable for multiple passageways
Standared function &features
1 . Alarm function:when arms are pushed by force illegally, alarm will be triggered automatically and arms will be set locked.turnstile can check by itself when it is have problem, it is good for customer to maintain and use
2 . Turnstile can setting the working condition by press the button of main control board.
3 . This model is newest second generation of movement (mute), soft baffle (PU mold)
4 . Anti-pinch function: turnstile have Mechanical/ infrared induction Anti-pinch functions( when it is meet the hinder during the reset time, the electrical machine closed work automatically in specified time, the turnstile will default the delayed and reset again till reset succeed)
5 . The turnstile will closed the door when somebody enter the gate illegal, Tailgating or break into negative direction gate.
6 . Before received the open signal, the turnstile will lock automatically
7 . Automatic Reset Functions: after you swap the card, during the specific time (the system is 10s), if you didn’t pass the turnstile, the system will cancel your authority automatically to pass the gate
8 . Infrared reset function & Infrared induction clamp function (Optional:3 pairs or 5 pairs Infrared)
Extended Function
1 . LED indicator light
2. Voice Prompt Function
3 . Box body can lengthen, telescopic arm color can choose
4 . Infrared logical judgment function (you can choose 7 pairs or 9 pairs Infrared)
5 . Normally open or closed can be adjust to meet the requirements of the different place.
6 . Sound and light alarm prompt functions
Goldantell product application
Subway Station, Bus Station,Airports, Hoverport, Terminal,Tourism Sports,Exhibition, Hotel,Factory,Bank,Prison,Hospital,School,Library,Theater,Canteen,Swimming Hall,Fitness Gym, Residence Area,Enterprise’s Entrance and Exit Attendance,Gateway Guard,Toll Management,Special Access Control.
About the package
1 . One pair need two packages.
2 . If with access control system, need closed wooden box packing.
3 . Without the access control system, two ways for your choice: crate and closed wooden box.
About access control system
we can offer access control system: fingerprint/ face recognition/ QR code/ card reader/ barcode ticket system/ ESD tester system also support special function: counter, coin- operation.
All this customize according to your needs.
Goldantell Competitive Advantage
1 . More than 9 years powerful ODM/OEM ability,could make product shape design,custom logo,custom package.
2 . We can provide not only product, but also system software management.Save your time and cost.
3 . About after sales problem :
For repairing,no need you return back product,only need you take a video,our engineer will instruct you,if spare parts was damaged within1 year(exclusion of human factors ),we will send you spare parts by fastest express,you no need bear any fee.
4 . Friendly and professional customer service people help you in 16 hours.
