Bi Direction Fingerprint Turnstile Security Gates Waterproof IP54

Bi Direction Fingerprint Turnstile Security Gates Waterproof IP54
Bi Direction Fingerprint Turnstile Security Gates Waterproof IP54 Bi Direction Fingerprint Turnstile Security Gates Waterproof IP54

Large Image :  Bi Direction Fingerprint Turnstile Security Gates Waterproof IP54

Product Details:
Place of Origin: Guangdong,China
Brand Name: Goldantell
Certification: CE/ROHS/FCC/IS9001
Model Number: GAT-211
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: negotiation
Packaging Details: Packed in carton firstly,and then reinforced with export wooden case for outer packing
Delivery Time: 7 working days after received your payment
Payment Terms: T/T ,western Union,LC,Paypal
Supply Ability: 2,000pcs per month
Detailed Product Description
Product Name: 304 SUS Flap Turnstile Material: 304 Stainless Steel/316 Stainless Steel
Size Of Product: 600mm (L) * 300mm (W) * 990mm (H) Application: Indoor&outdoor
Net Weight: 50KG Gross Weight: 60KG
Communication Port: RS485 ,TCP/IP Compatible: RFID Reader&Fingerprint Reader ,Coin Access,QR Code Reader,Bar Code System,ESD Tester Access Control, Remote Button
Highlight:

Flap Barrier Turnstile

,

automatic flap barrier



Bi Direction Fingerprint Turnstile Security Gates Waterproof IP54





Specifications:



Item

GAT-211-1( single motor )
GAT-211-2( double motors )



Name

Bridge type sharp flap turnstile



Technical parameters



Working voltage:

AC220±10%V 50±10%HZ



Size:

600mm (L) * 300mm (W) * 990mm (H)



Retractable arm
length:

260 mm



Pass speed:

40 persons/min (open),

25-30 persons/min (closed)



Passage width:

≤600mm



Normal running life:

3 million



Time of opening/closing:

0.6 second



Time to work after
power on:

3 seconds

Reset time after
break down:

10 seconds
Direction:

single or bi-directional (optional)



Drive motor:

DC 24 V brush motor



Working environment:

indoor/outdoor (with a tent over)
-10℃~70℃



Communication
interface:

standard RS 485 interface,
distance ≤1200m



Input interface:

+12V level signal or pulse
width>100 ms 12V pulse, drive current>10 mA



Relative humidity:

≤90% coagulation free



Housing material:

domestic standard 304#

stainless steel








Description:



1 . With a self-test and alarm function, user-friendly maintenance and use



2 . Through the main control on the half-built small-press plate, programmable devices running status



3 . Mechanical structure, sensor features dual anti-trap, in the process of telescopic boom reset when you meet resistance, automatically stop or in the default time motor stopped working



4 . Sound, light alarm functions, including unlawful entry, trailing alarm



5 . Erosion control features, in the absence of gate opening signal is received, the arm automatically locked



6 . Telescopic synchronization



7 . With automatic reset function, gate opening, after a specified period of time does not pass; the system will automatically cancel the user's current access permissions



8 . Power off automatically after the channel open, power-on self-closing



9 . Connecting with a variety of reading devices which can be linked to the work of receiving the signal relay switch



10 . May be one-way or two-way control personnel access to



11 . Managing computer directly through the remote control and management



12 . Counting function can be expanded



13 . Chassis lengthened, telescopic boom material selection







Applications:



Wing turnstiles are mainly used in parks, subway, customers, airport, bus station, office building, scenic



spot, community, attractions, and exhibition hall doors, residential, Construction Sites, Industrial Plants,



Marquee Golf Tournaments, State Fairs, Special Sporting Events and Festivals







Competitive Advantage:



1. 1.2m thickness 304 stainless steel



2. RFID card (IC/ID), Barcode, fingerprint, control accepted



3. CE and ISO 9001-2008 certified



4. OEM and ODM are welcome.





Bi Direction Fingerprint Turnstile Security Gates Waterproof IP54 0
