Model No.
|
GAT-504 |
|
Framework Material
|
304 Stainless Steel |
|
Dimension
|
1630 (L) * 1500 (W) * 2300 (H) mm |
|
Net Weight
|
300kg |
|
Passage Width
|
650mm |
|
Passing Direction
|
Single directional / Bi-directional |
|
Power Supply
|
AC220V/110V, 50/60Hz |
|
Operation Voltage
|
24V DC |
|
Power Consumption
|
40W |
|
Operation Temperature
|
-15 °C – 60 °C |
|
Operation Humidity
|
0 ~ 95% (No freeze) |
|
Working Environment
|
Indoor / Outdoor (Shelter) |
|
Flow Rate
|
35-40 people per minute |
|
LED Indicator
|
Yes |
|
Input
|
Dry contact |
|
Emergency
|
Automatic arm open when power off |
|
Communication
|
RS485, TCP/IP |
Features
- The whole system runs smoothly, long-life performance, high operation dependability and fast response.
- The mechanism is equipped with an automatic regulated hydraulic buffer device. No noise and impact when running.
- Self-test function, when power on, system restoration automatic.
- Dual-bearing device, keeping the gate in balance when there is external force.
- Single directional or Bi-directional is selectable.
- LED indicator.
- Automatic reset function: when Full Height Turnstile receives an open single, but passenger do not pass through the hallway within a specific time (default 5s), turnstile arm will lock automatically. Limit passing time (01-60 seconds), passing time can be set on Full Height Turnstile circuit board.
- When power off, turnstile lane will be free to pass, complying with fire safety requirements.
Appearance, Dimension, Material & Surface Finish
Appearance: customized according to customer’s requirement.
Stainless steel thickness of the cabinet: customized within 1.2~2.0mm.
Material of the cabinet: 304 / 316 grade stainless steel.
Surface finish of the cabinet: satin finish / polishing / anti-fingerprint/frosted finish / electroplating / baking finish.
System Integration
Integrate with access control system required by customers, and built-in reader appointed by customer.
Integrate with visitor management system.
Integrate with ticketing system.
Direction Indicator
The installation position of direction indicator can be adjusted.
The pattern of direction indicator can be customized.
Application:
Subway Station, Bus Station,Airports, Hoverport, Terminal,Tourism Sports,Exhibition,
Hotel,Factory,Bank,Prison,Hospital,School,Library,Theater,Canteen,Swimming Hall,Fitness Gym,
Residence Area,Enterprise’s Entrance and Exit Attendance,Gateway Guard,Toll Management,Special
Access Control
