High Accuracy Single-Foot ESD Tester for Wrist Strap & Footwear Personnel Anti-static Body Static Compliance Checker for Lab

  • High Accuracy Single-Foot ESD Tester for Wrist Strap & Footwear Personnel Anti-static Body Static Compliance Checker for Lab
Place of Origin Guangdong,China
Brand Name Goldantell
Certification CE certificated
Model Number GAT-ESD304
Document Different ESD Tester turnst...ll.pdf
Minimum Order Quantity Negotiable
Price negotiation
Packaging Details wooden case
Delivery Time 5-7 working days after received your payment
Payment Terms T/T,western Union,LC,Paypal
Supply Ability 2,000pcs per month
Product Details
Power Supply 220 / 110 V(AC) Display Screen Size 8 Inches
Communication RS485 Working Environment Indoor / Outdoor ( Shelter),-10-50℃
Pedal Size 400mm (W) * 420mm (L) * 20mm (H) Operating Voltage Input AC220V, Output DC12V
Environmental Conditions Humidity: 0%-90%, Temperature: 5°C-40°C Test Range Accuracy Left Shoe: 0.01-1000MΩ (±5%), Right Shoe: 0.01-1000MΩ (±5%), Wrist-strap: 0.1-35MΩ (±5%)
Highlight

Single-Foot ESD Tester for Wrist Strap

,

ESD Tester for Footwear Personnel

,

Anti-static Body Static Compliance Checker
Leave a Message
Product Description
High Accuracy Single-Foot ESD Tester for Wrist Strap & Footwear Personnel Anti-static Body Static Compliance Checker for Lab
Product Overview

Networked ESD Test Station with Software HID Proximity Card Reader Static Monitoring Access Control for SMT Audit Compliance

Key Features
  • Supports HID Proximity Cards: Secure access control for SMT audit compliance
  • Networked ESD Test Station: Ensures static monitoring and access control
  • 8-inch Touch Screen: Static monitoring detects and prevents static discharge issues in SMT environments
Technical Specifications
Parameter Specification
Instrument Dimensions 8 inch LCD monitor: displays user information including photo, name, card ID, department, entry time, etc.
Pedal Size 400mm (W) * 420mm (L) * 20mm (H)
Operating Voltage Input AC220V, Output DC12V
Working Hours Unlimited
Environmental Conditions Humidity: 0%-90%, Temperature: 5°C-40°C
Data Storage Automatically stores records and ESD test data (except client mode), capacity for 100,000+ records
Test Range and Accuracy Left shoe: 0.01-1000MΩ (±5%)
Right shoe: 0.01-1000MΩ (±5%)
Wrist-strap: 0.1-35MΩ (±5%)
Note: Test range limits can be adjusted to meet customer requirements.
Technology Parameters
  • Online data saving capability with signal output
  • Comes with related software, tester, and optional voice prompts
  • Employee card access control functionality
  • Simultaneous testing of three independent devices (Left Shoes, Right Shoes, Wrist Strap)
  • Compatible with SQL Server 2000/2008 for access control management
  • TCP/IP communication technology supports connection of up to 255 testing devices
  • Real-time monitoring of employee compliance with anti-static requirements
Operational Modes
  • Mode 1: Simultaneous Hand and Foot Detection
    Ideal for production line operators
  • Mode 2: Foot-Only Detection
    Suitable for workshop visitors not directly handling products (QC, warehouse staff)
  • Mode 3: Hand-Only Detection
    Designed for assembly line or logistics personnel
  • Mode 4: Free Test Card
    Allows direct access for management/customer inspections
All modes are software-configurable with automatic employee authority recognition. Different test card permissions can be set according to specific requirements.
