ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester

Large Image : ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	Goldantell
Certification:	CE
Model Number:	GAT-ESD305
Document:	Goldantell Turnstile & Faci...og.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	2
Price:	$1,380-1,500

Contact Now

Detailed Product Description

Display Size:	8 Inches	Power Supply:	220 / 110 V(AC)
Operating Voltage:	Input AC220V Output DC12V	Pass Speed:	30-40 Persons/min
Interface:	RS485, TCP/IP	Material:	Stainless Steel
Working Temperature:	-15~+75 °C	Environmental Temperature:	5°C~40°C
Humidity Range:	0%~90%	Pedal Size:	W 400 X L 420 X H 20 (mm)
Left Shoe Range:	0.01-1000MΩ	Right Shoe Range:	0.01-1000MΩ
Wrist-strap Range:	0.1-35MΩ	Left Shoe Accuracy:	±5%
Right Shoe Accuracy:	±5%	Wrist-strap Accuracy:	±5%
Highlight:	ESD gate with RFID card reader , 8 inch screen ESD gate , wrist strap tester ESD gate

Built-in Computer Internet Interface RFID Card Reader with Optional 8-inch Screen ESD Wrist Strap & Footwear Tester

Product Attributes

Attribute	Value
Type	Card, ESD
Special Features	Touch Screen, Time & Attendance
Network	WiFi
Power supply	220 / 110 V(AC)
Pass speed	30-40 persons/min
Interface	RS485, TCP/IP
Display Screen Size	8 inches
Material	Stainless steel
Working temperature	-15~+75 °C
Transmission	All-electric mechanical
Working environments	Indoor/Outdoor
Application	Indoor

Product Description

This built-in computer internet interface RFID card reader with optional 8-inch screen ESD tester system combines advanced access control with comprehensive electrostatic discharge protection.

Technology Parameters

Online data saving capability with signal output
8-inch display monitor with related software included
Optional voice prompts and employee card access control
Simultaneous testing of three independent devices (Left Shoes, Right Shoes, Wrist Strap)
Compatible with SQL Server 2000/2008 for access control management
TCP/IP communication supports connection of up to 255 testing equipment units
Real-time monitoring of employee compliance with anti-static requirements

Specifications

1	Instrument Dimensions	8 inch LCD monitor: displays all user info including photo, name, card ID, department, entry time, etc.
2	Pedal size	W 400 x L 420 x H 20 (mm)
3	Operating voltage	Input AC220V output DC12V
4	Working hours	Unlimited
5	Environmental conditions	Humidity: 0%~90%, Temperature: 5°C~40°C
6	Data storage	Automatically stores records and ESD test data (except client mode), recording information up to 100,000 or more
7	Test Range and Accuracy	Left shoe: 0.01-1000MΩ, Accuracy ±5% Right shoe: 0.01-1000MΩ, Accuracy ±5% Wrist-strap: 0.1-35MΩ, Accuracy ±5%

Features & Functions

ESD tester system offers 4 operational modes:

Simultaneous hand and foot detection: Ideal for line operators
Foot detection only: Suitable for non-direct product handlers like QC and warehouse staff
Hand detection only: Designed for assembly line or logistics personnel
Free test card mode: For management/customer inspections with direct card access

Note: All modes are software-configurable with automatic employee authority recognition through card reading.

ESD Gate with RFID Card Reader 8 Inch Screen Wrist Strap Tester 1

Configuration Options

Flap Turnstile Gate + ESD tester system GAT-ESD305: Includes software and card access control system with 8-inch LCD monitor and enhanced ESD test range (0.01-1000MΩ for shoes, 0.1-35MΩ for wrist-strap)
Flap Turnstile Gate + Basic ESD tester: Combines with RFID card reader but without display screen or control software

Certifications

Company Profile

Shenzhen Goldantell Technologies Co., Ltd is a leading exporter and supply chain service provider of intelligent turnstile and parking management products with over 13 years of experience.

Our product range includes intelligent turnstiles, parking barriers, RFID cards, sentry boxes, wheel clamps, and related security access control systems. We have exported to more than 50 countries and established long-term partnerships with clients worldwide.
