IR Sensor Flap Barrier Turnstile High Security Full Auto Servo Motor For Airport
| Place of Origin | Guangdong,China |
|---|---|
| Brand Name | Goldantell |
| Certification | CE/ROHS/FCC/IS9001 |
| Model Number | GAT-205 |
| Minimum Order Quantity | 1pcs |
| Price | negotiation |
| Packaging Details | Packed in carton firstly,and then reinforced with export wooden case for outer packing |
| Delivery Time | 7 working days after received your payment |
| Payment Terms | T/T,western Union,LC,Paypal |
| Supply Ability | 1,000pcs per month |
Contact me for free samples and coupons.
WhatsAPP:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Application | Office\School\Airport\Subway\Outdoor | Dimension | 1200 * 280 * 1000mm |
|---|---|---|---|
| Power Supply | AC100V-240V | Passing Speed | 45persons/min |
| Driving Motor | 24V Brushless DC Motor | Usage | Subway Station Mall |
| Material | Stainless Steel 304/316 | Lane Width | 60,90,110cm Or Others |
| Highlight | IR Sensor Flap Barrier Turnstile,Flap Barrier Turnstile For Airport |
||
Product Description
IR Sensor Flap Barrier Turnstile High Security Full Auto Servo Motor For Airport
High Security Full auto Servo Motor IR sensor turnstile for Airport Border tourniquet system Barrier Gate
Automatic Flap Barrier Features
- Goldantell intelligent Series turnstile gates feature excellent design and performance, utilizing innovative technology and high-quality materials for security, commercial, and industrial applications.
- Electric control with DC motor ensures stable, reliable operation with low failure rate. Ultra-bright LED directional indicators provide clear visibility.
- System integration compatible with Face, thermal, RFID, fingerprint, QR/barcode, and ESD access control systems.
- Custom OEM/ODM services available for size, shape, and other specifications.
- Constructed with 304 stainless steel (IP54 waterproof rating), featuring elegant anti-rust design for durability.
Automatic Flap Barrier Specifications
| 1 | Cabinet dimension | 1200 (L) x 280 (W) x 1000 (H) mm |
|---|---|---|
| 2 | Cabinet material | 304 stainless steel (316 ss can be custom-made) |
| 3 | Switching power supply | AC220±10%V 50Hz or AC110±10%V 60Hz |
| 4 | Opening/closing time | 0.2s |
| 5 | Arm material | Thickness 10mm Acrylic, or tempered glass or steel (custom) |
| 6 | Access mode | Single in/out or Bidirectional |
| 7 | Passthrough Width | 900mm (or custom) |
| 8 | Mechanism | DC Brushed motor+Clutch (or Servo motor) |
| 9 | Communication interface | RS485, TCP/IP |
| 10 | Infrared sensor | 6~10 pairs |
| 11 | Optimal flow rate | 40 persons/min (open), 35 persons/min (closed) |
| 12 | Reset time after break down | Default 10s (adjustable) |
| 13 | MCBF | 5,000,000 Cycles |
| 14 | Working humidity | 30%~95% |
Standard Features
- Bi-directional or single way operation options
- Gate auto-opens during power failure to meet fire safety requirements
- Anti-Tail gaiting feature prevents unauthorized entry
- Multiple alarm modes: illegal intrusion, anti-intrusion, anti-follow, overtime alarm
- Wings open automatically during power interruption (optional NC mode recovery)
- Fast opening and closing operation
- Built-in mechanical lock prevents forced opening
- Multiple pairs of IR sensors
Operation Applications
Bank
Fitness Gym
Factory
Hotel
Movie theaters
Office buildings
Our Services
1. Friendly and professional customer service available 16 hours daily.
2. Over 10 years of ODM/OEM experience including custom product design, logos, and packaging.
3. Comprehensive solutions including product and system software management to save time and costs.
4. Special repair service: Video-based troubleshooting with free spare parts replacement within 1 year warranty.
Our Advantages
- 13+ years specialization in turnstile systems
- Custom OEM/ODM services available
- Cost-optimized designs eliminating unnecessary features
- Rapid response time (3 minutes) for all customer inquiries
Packaging Options
- Export: Wooden case with pearl wool and plastic wrap (inspection exempt)
- Domestic: Bubble wrap with carton or pearl wool with wooden packaging
- Professional, environmentally friendly packaging services
Frequently Asked Questions
Can I have a system that only supports ESD test without software?
Yes, we offer multiple options. Our catalog can help you make the right choice.
What language versions are available for the software system and machine display?
English and Chinese versions available.
Can I get software manuals or installation instructions?
Yes, English version manuals are available.
Can I customize the product?
Yes, we specialize in OEM/ODM services with extensive experience serving government and other sectors.
What are your payment terms?
100% payment before shipment. We provide product and package photos/videos before final payment.
What are your delivery terms?
EXW, FOB, CFR, CIF, DDU available.
