Product Details:
Payment & Shipping Terms:
|
Product Name: | 304 SUS Flap Turnstile | Size Of Product: | 1200*280*1000mm |
---|---|---|---|
Package Size: | 1280*370*1070mm | Application: | Indoor&outdoor |
Net Weight: | 65KG | Gross Weight: | 70KG |
Communication Port: | RS485 ,TCP/IP | Compatible: | RFID Reader&Fingerprint Reader ,Coin Access,QR Code Reader,Bar Code System,ESD Tester Access Control, Remote Button |
Material: | 304 Stainless Steel/316 Stainless Steel | ||
High Light: | LCD Screen flap turnstile Gate,304SUS flap turnstile Gate,TCP IP access control turnstile Gate |
Safety Passage gate access control system with LCD screen qr code reader turnstile price nfc reader
Description Of Gate Access Control System
1. Flap barrier series is widely used in airports, subway stations, and railway stations , docks, scenic spots, parks, student dormitories, pedestrian passages, etc.
2. It can be compatible with Face, thermal, RFID / fingerprint / QR or barcode / ESD access control system, to manage.
3. LED indicator light: green and red indicate the passing information.
4. Single lane or multiple lane set-up
5. Special stretch wing design, save closing time, improve the passage speed, prevent trailing , increase the security level.
Specifications Of Gate Access Control System
Item |
( single motor ), OR ( double motors ) |
Name |
Bridge type flap turnstile |
Size: |
1200mm (L) * 300mm (W) * 1000mm (H) |
Retractable arm length: |
260 mm |
Pass speed: |
40 persons/min (open), 25-30 persons/min (closed) |
Passage width: | ≤600mm |
Normal running life: | 3 million |
Time of opening/closing: | 0.6 second |
Time to work after power on: |
3 seconds |
Reset time after break down: |
10 seconds |
Direction: | single or bi-directional (optional) |
Drive motor: | DC 24 V brush motor |
Working environment: |
indoor/outdoor (with a tent over) -10℃~70℃ |
Communication interface: |
standard RS 485 interface, distance ≤1200m |
Input interface: |
+12V level signal or pulse width>100 ms |
Relative humidity: | ≤90% coagulation free |
Housing material: |
domestic standard 304 # stainless steel |
Working voltage: | AC220±10%V 50±10%HZ |
Function Of Gate Access Control System
1. Infrared reset function (Optional:4 pairs or 6 pairs Infrared). Infrared induction clamp function.
2. The turnstile is bidirectional (pedestrian can enter and exit from one pair of turnstiles).
3. Real time trouble self-detect and alarm indication, ensuring system safe operation and facilitating maintenance and operation
4. To select a reasonable normally open or close mode, to divert the flow of passengers effectively.
5. Setting function humanized for reset of over time passing.
6. Can manager and long-range control the turnstile directly by managing the computer.
7. Flashing light prompt function: it is convenient to find the turnstile problem by administrative staff.
Special function Of Gate Access Control System
1. LED counting function
2. Box house can lengthen, swing arm lengthen
3. Infrared logical judgment function (you can choose 8 pairs or 10 pairs Infrared) Voice Prompt Function
4. Normally open or closed can be adjust to meet the requirements of the different place. Sound and light alarm prompt functions
5. Stroboscopic lamp prompt function: site administrator can find the turnstile problem quickly and accurately.
Layout Of Gate Access Control System
1. Multiple lanes ( 2, 3, 4 or more channels, passageway required);
2. Single-lane (channel), as shown below, use two units of a single-motor machine.
Packing Of Gate Access Control System
1. Inside with a carton package.Then outside,there are 2 kinds of packages under your choice:
2. crate package and closed wooden package optional.
FAQ Of Gate Access Control System
Q: How long is your warranty period?
A: Standard One-year guarantee & lifetime technical support.
Q: How about the lead time?
A: Regular products need 7-10 working days; the customized products need 10-15 working days.
Q: What is the flap gate Working environment?
A: They can be used indoor and outdoor (added the rain shed)
Q. Can I customize it?
A: Yes, Welcome. We are the manufacturer, we have rich OEM/ODM experience for government, etc.
Project Of Gate Access Control System
1. Public Places: lobby entry, Subway, Airports, Stations,Library, Bookstores, Parks, Exhibition halls, Stadium, Museums,Apartments,Residence Area, Offices,Commercial buildings.
2. Entertainment Places: Movie theaters, Fitness halls, Country clubs, Fairground, Clubs,Swimming Hall, Fitness Gym.
3. Business Organizations: Hotel,Factory,Bank,Prison,Hospital,School, Enterprise’s Entrance and Exit Attendance.
