Product Details:
Payment & Shipping Terms:
|
| Warranty: | 1year Free Guaranty Service | IP: | 54 |
|---|---|---|---|
| Product Name: | Automatic Half Turnstile Access Control For Gym | Power Supply: | AC220V/110V Optional |
| Application: | Office,Club,Company | Transit Speed: | 35 Persons/min |
| Passage Width: | <= 60cm | Dimension: | L1200 X W300 X H1000mm |
| High Light: | Auto Reset Flap Barrier Gate,Goldantell Flap Barrier Gate,220v AC Flap Barrier Turnstile |
||
Entrance And Exit Gate Card fingerprint scan Manufactory direct esd turnstile door auto reset turnstile bridge gate
Our Turnstile can combine with different kinds of access readers,like: RFID Reader&Fingerprint Reader &Coin Machine&Barcode System&ESD Tester Access Control(If you have access control system,you can only purchase our turnstiles,if not, our side will install the access control system for you),except acess system,also can use remote(this is free gift to you).
Technical specification
| Item NO. | GAT-206 |
| Cabinet dimension | 1200/1400 (L) x 300 (W) x 1000 (H) mm |
| Cabinet material | 304 stainless steel (316 ss can be custom-made) |
| Switching power supply | AC220±10%V 50Hz or AC110±10%V 60Hz |
| Flap opening/closing time | 0.6-0.8s |
| Stretching-out flap length | 285 mm for single wing; if for the disable access, can lengthen |
| Access mode | single in/out or Bidirectional |
| Optimal flow rate | 40 persons/min (open), 25-30 persons/min (closed) |
| Reset time after break down | default 10s,can be changed to fit different demands |
Features
◊ Smart card reader compatible with a variety of card such as IC and ID card.
◊ Can be expanded to automatic identification system, realizing function of access control,pedestrian flow control,attendance check or fare collection.
◊ Equipped with international standard electrical interface, can be easily integrated with other R/W device, also can be controlled and management through remote supervision computer
◊ Equipped with a couple of infrared photocell, alarm at unauthorized entry or tailgating attempts, together with anti-strike function to protect pedestrian
◊ LED gate direction indicator that displays the current operational state to pedestrian. Green arrow for entry free, Red cross for passage locked.
◊ Can open the turnstile by two input signals (signals can be input by access controller, button or other equipments
◊ Provide audible sound prompt and information display function.
◊ The flaps will open automatically during power interruption, and recover N/C mode after power on(optional).
Application & Instruction
1 Flap Wing Color-- Blue, red ,more options
2 LED directional sign
3 Top LCD display screen
