Shenzhen high quality tandem pedestrian access control gate fix rotational turnstile with fours arm revolving

  • Shenzhen high quality tandem pedestrian access control gate fix rotational turnstile with fours arm revolving
  • Shenzhen high quality tandem pedestrian access control gate fix rotational turnstile with fours arm revolving
Place of Origin Guangdong,China
Brand Name Goldantell
Certification CE/ROHS /IS9001
Model Number GAT-503
Minimum Order Quantity 1pc
Price negotiation
Packaging Details Packed in carton firstly,and then reinforced with export wooden case for outer packing
Delivery Time 7 working days after received your payment
Payment Terms T/T,Western Union,L/C,Paypal
Supply Ability 2,000pcs per month

Contact me for free samples and coupons.

WhatsAPP:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Size 210(L)* 135(W)* 225(H)CM Material 316 / 304 Stainless Steel
Compatible RFID Reader&Fingerprint Reader ,Coin Acess,QR Code Reader,Bar Code System,ESD Tester Access Control, Remote Button Communication Port RS485 ,TCP/IP
Application Prison, Factory, Government Etc. Verification RFID, Fingerprint, Facial Optional
Direction One-way, Bi-direction Adjustable Passage Width 60-65cm
Opening Speed 25-30 Persons Per Min
Highlight

65cm full body turnstile

,

ss316 full height gate
Leave a Message
Product Description
Shenzhen High Quality Tandem Pedestrian Access Control Gate
Fixed Rotational Turnstile with Four Arm Revolving
The body is constructed from brushed stainless steel for a seamless, elegant design. Three arms rotate in one or two directions via controlled drive mechanism. Emergency unlocking is available both manually and automatically. Features a robust mechanism with intelligent control unit for reliable performance in high-traffic environments with smooth operation. Designed for integration with various access control systems including RFID, fingerprint, QR code, barcode, ticket, ESD testing, and facial recognition.
Functions & Features
Standard Features
  • Low noise operation with no mechanical impact
  • Single or bi-directional operation
  • High-speed operation with quick response
  • Premium design with high-quality construction
  • Robust, rigid, anti-rust and durable
  • Smooth working system
  • Self-test function
Added Functions
  • Counting function available (counter)
  • Information display option (LCD screen)
  • Audible sound prompt
  • Invalid entry alarm
  • Auto-lift-arm function (fully automatic type)
Specifications
Power AC100-240V, 50/60HZ
Passage Width 600 mm (customizable)
Operating Temperature -15°C to 75°C
Relative Humidity ≤95%, No Condensation
Communication Distance ≤1200m
Passing Speed 25-30 persons/min (IC Card/ID Card)
Motor 0.5NM/24V (Fully Automatic)
Input Connection +12V Level Signal or Pulse Wide>100ms DC12V
Communication Connection RS485 Communication Module Standard
Material SUS304 or Carbon Steel Powder Coating
Direction Single or bi-directional (optional)
Time of Opening 1-2 seconds
Customization Options
Rotary Arms: Available in straight or "U" shape; four arms or three arms (90°/120° configuration).
Waterproof Enclosure: Includes stainless steel box for installing biometric readers (waterproof for outdoor use). Options include RFID card reader only or combined fingerprint + card reader.
Additional Features
  • LED indicator light (optional)
  • Fingerprint reader (optional, other control methods available: push button, coin-operation, card reader systems)
  • Advanced control board for full height turnstile
  • Material options: Standard 304 stainless steel or optional 316 grade
