Mifare Card Automatic Full Height Turnstiles Prison / Bank / Construction IP62 50Hz

Prison / Stadium / Bank / Construction Site Mifare Card Automatic Full

Height Turnstile IP62 Reader Box

Technical parameters of contruction site full height turnstile

1, The Power:AC220V±20%V,50Hz

2, Working Temperature:-40℃--70℃

3, Relative Humidity:0-95%

4, Passing Speed:30 persons/min

5, Driving Motor: DC24V

6, Led Indicator:2

7, Communication Interface: Rs485(Distance less than 1200m)

8, Framework Material: 304 or 316 stainless steel

9, Working environment: indoor/ outdoor

10, Service Life:3.8-4 million times

Features of construction site full height turnstile

1 Automatically low noise mechanism core equipped,highly cost-performance

2 Sense positioning ,reducing mechanical impact make lifetime longer

3 Operating efficiency,1~2 seconds open & close

4 Lowest Noise : No matter in operating or outside control ,Noise control under 30db

5 Self-checking and Alarm warning for maintain

6 Resetting :System cancel authorized pass if passenger delayed pass

7 Anti following : prevent illegal passing

8 Anti clamp :The wings will stopped during in external block .the wings reset again after default delay

9 The rotary wings will be locked automatically if the system do not receive IR signal

10 Multi-passage for variety application demands ,Cover 99% needs on earth

11 Programmable signal separate control : pass time,pass speed etc. parameters

12 RS232/RS485 interface meet all kind of communications or WIRELESS connection

13 Compatible IC/ID card ,flexible couple

14 Long-distance management through COMPUTER

15 Customize Options : LED display,Voice guide ,Warning Lamps,Indicator Lights guide, Audible &Visible

Alarm
